Key Features:

• Versatile Sizing: The Radial Slewing Liferaft Davit is available in various sizes, making it suitable for handling a wide range of davit-launched liferafts, accommodating capacities from 12 persons up to 39 persons.

• Components Included:

  • Pedestal suitable for welding to the deck.
  • Column with an integrated manually driven slewing gear.
  • Arm constructed in a box shape for robust support.
  • Liferaft winch with a centrifugal brake (optionally available with an electric motor for hoisting operations).
  • Wire rope made of galvanized non-rotating steel for corrosion resistance.
  • Automatic release stainless steel hook for secure liferaft attachment.
  • Remote control of the stop-go type for convenient operation.



• Optional Multiple Raft Handling: Additionally, the system can be equipped for handling a second liferaft with features like a liferaft winch with quick return for multiple raft handling and a jockey pulley for retrieving the empty hook.

• Stores Handling Features: For handling stores, the system includes a stores winch with an electric motor in IP56, an electric system with a stainless steel starter box with push buttons, galvanized non-rotating steel wire rope, and suspension in compliance with the latest DIN standards.

• Optional Features: Optional features include an electric remote control for the stores winch, an electric winch motor for hoisting operations, and a floodlight on the arm connected to the ship's emergency circuit.
