SPECIFICATIONS
| Capacity |
Rated: | Overload: 13 Persons |
| Approval |
USA: FAA TSO-C70a, Type II |
| Color | Tube: Yellow Canopy: Fluorescent Orange Carrying Case: Yellow |
| Diameter Raft Tube | 14.25" (36.2 cm) |
| Inflated Volume: @ 1.50 psig |
26.86 ft³ (0.7606 m³) |
| Tube Volume Per Person: @ rated capacity | 2.984 ft³ (0.0845 m³) |
| Total Tube Buoyancy | 1676 lbs. (760.2 kg) |
| Buoyancy Per Person: @ rated capacity | 186.2 lbs. (84.47 kg) |
| Total Deck Area | 33.0 ft² (3.07 m²) |
| Deck Area Per Person: @ rated capacity | 3.67 ft² (0.341 m²) |
| Tube Operating Pressure |
Nominal: 2.0 psig (0.14 bar) |
| Pressure Relief Valves |
Open: 2.5 - 3.0 psig (0.17 - 0.21 bar) |
| Tube Burst Pressure | Over 6 psig (0.4 bar) |
| Inflation System |
Cylinder Size: 205 in³ |
| Environmental Limits | |
| Temperature | |
| Humidity |
Up to 95% relative humidity |
| Altitude | -2000 to 45,000 ft. above sea level |
| Service Life |
Indefinite if raft continues to pass periodic maintenance inspection |
| Frequency Of Inspection |
12 months from in-service date or 24 months from date of manufacture for first maintenance inspection, every 12 months for subsequent inspections |
