SPECIFICATIONS
| Capacity |
Rated: | Overload: 9 Persons |
| Approval |
USA: FAA TSO-C70a, Type I |
| Color | Tube: Yellow Canopy: Fluorescent Orange Stabilizing Bags: Fluorescent Orange Carrying Case: Yellow |
| Diameter Raft Tube | 10.25" (260.4mm) |
| Inflated Volume: @ 1.50 psig |
Tube 1: 11.2 ft³ (1.04 m³) |
| Tube Volume Per Person: @ rated capacity | 3.91 ft³ (0.111 m³) |
| Total Tube Buoyancy | 1100 lbs. (499.0 kg) |
| Buoyancy Per Person: @ rated capacity | 183.3 lbs. (83.16 kg) |
| Total Deck Area | 22.1 ft² (2.05 m²) |
| Deck Area Per Person: @ rated capacity | 3.68 ft² (0.342 m²) |
| Tube Operating Pressure |
Minimum: 1.5 psig (0.10 bar) |
| Pressure Relief Valves |
Open: 2.5-2.7 psig (0.17-0.19 bar) |
| Tube Burst Pressure | Over 6 psig (0.4 bar) |
| Inflation System |
CO₂/N₂ System (1 cylinder) Cylinder Material: Charge Weights: CO₂ : 1.00 to 1.02 lbs (0.434 to 0.462 kg) |
| Environmental Limits | |
| Temperature | |
| Humidity |
Up to 95% relative humidity |
| Altitude | -2000 to 45,000 ft. above sea level |
| Service Life |
Indefinite if raft continues to pass periodic maintenance inspection |
| Frequency Of Inspection |
36 months from last compressed gas cylinder hydro test date for first maintenance inspection, every 36 months for subsequent inspections |
