SPECIFICATIONS
| Capacity |
Rated: | Overload: 69 Persons |
| Approval |
USA: FAA TSO-C70a, Type I |
| Color | Tube: Yellow Canopy: Fluorescent Orange Carrying Case: Yellow |
| Diameter Raft Tube | 16.25" (41.28cm) |
| Inflated Volume: @ 1.50 psig |
Tube 1: 75.2 ft³ (2.13 m³) |
| Tube Volume Per Person: @ rated capacity | 3.27 ft³ (0.0926 m³) |
| Total Tube Buoyancy | 9422 lbs. (4274 kg) |
| Buoyancy Per Person: @ rated capacity | 204.8 lbs. (92.91 kg) |
| Total Deck Area | 166 ft² (15.4 m²) |
| Deck Area Per Person: @ rated capacity | 3.61 ft² (0.335 m²) |
| Tube Operating Pressure |
Minimum: 1.5 psig (0.10 bar) |
| Pressure Relief Valves |
R0202A3XX: |
| Tube Burst Pressure | Over 6 psig (0.4 bar) |
| Inflation System |
R0202A2XX: R0202A3XX: |
| Environmental Limits | |
| Temperature | |
| Humidity |
Up to 95% relative humidity |
| Altitude | -2000 to 45,000 ft. above sea level |
| Service Life |
Indefinite if raft continues to pass periodic maintenance inspection |
| Frequency Of Inspection |
36 months from the date of manufacture for first maintenance inspection, every 36 months for subsequent inspections |
