SPECIFICATIONS
| Capacity |
Rated: | Overload: 54 Persons |
| Approval |
USA: FAA TSO-C70a, Type I |
| Color | Tube: Yellow Canopy: Fluorescent Orange Carrying Case: Yellow |
| Diameter Raft Tube | |
| Inflated Volume: @ 1.50 psig |
Tube 1: 52.1 ft³ (1.48 m³) |
| Tube Volume Per Person: @ rated capacity | 2.89 ft³ (0.082 m³) |
| Total Tube Buoyancy | 6168 lbs. (27440 N) |
| Buoyancy Per Person: @ rated capacity | 171 lbs. (761 N) |
| Total Deck Area | 133.72 ft² (12.423 m²) |
| Deck Area Per Person: @ rated capacity | 3.71 ft² (0.345 m²) |
| Tube Operating Pressure |
Minimum: 1.5 psig (0.10 bar) |
| Pressure Relief Valves |
Open: 2.5-2.7 psig (0.17-0.19 bar) |
| Tube Burst Pressure | Over 6 psig (0.4 bar) |
| Inflation System |
Cylinder Size: 285 in³ |
| Environmental Limits | |
| Temperature | |
| Humidity |
Up to 95% relative humidity |
| Altitude | -2000 to 45,000 ft. above sea level |
| Service Life |
Indefinite if raft continues to pass periodic maintenance inspection |
| Frequency Of Inspection |
36 months from the date of manufacture for first maintenance inspection, every 36 months for subsequent inspections |
